Installation of the 7023A GX Modem Unit (CX-751)

98-175666-D Chapter 2: Installation 2-37

I/O connector for Tx Mute and Rx Lock (future use)

The GMU 407023A has one I/O connector for Tx Mute and Rx Lock.

Outline (on the GMU) Pin Pin function

1 GND

2 Not connected

3 Rx Lock out

4 Tx Mute in

Table 2-28: I/O connector, outline and pin assignment, modem

(future use) (407023A)
