Introduction to the web interface
98-175666-D Chapter 3: Setup of the antenna 3-3
3.1.1 Connecting to the web interface
To connect to the web interface do as follows:
1. Switch on the BDU.
2. Wait until the LEDs on the front plate of the BDU show that the system is ready to be
configured.
• Power LED: Green
• Logon LED: Off
• Fail/Pass LED: Blinking green during power-on self test, after that steady green.
3. Connect a PC to the service port on the front panel of the BDU.
4. Open an Internet browser and enter the IP address of the BDU. The default IP
address is http://192.168.0.1. When the login screen is displayed you have verified
that the connection to the SAILOR XTR GX-R2 can be established.
There is an admin and a guest login. A guest can only access the functions that are
allowed by an administrator. With the guest login (user name: guest, password:
configured by the administrator) you can protect the system from accidental changes
of the configuration.
Figure 3-3: BDU, service port
Figure 3-4: Login
465
482.6
Service port
