Settings
98-175666-D Chapter 3: Setup of the antenna 3-12
BDU LAN port 3 - mode
BDU LAN 4 - mode
BDU LAN 5 - Mode:
Static + DHCP server: Used defined Network setup - VLAN 5
ADU LAN 1 - Mode
ADU LAN 2 - Mode
LAN port 1 Modem: LAN Port 3 assigned to LAN Port 1 VLAN / IP-subnet.
LAN port 5 Service: LAN Port 3 assigned to LAN Port 5 VLAN / IP-subnet.
ADU port 1 BDU LAN Port 3 + ADU LAN Port 1 assigned to VLAN 6
Static IP Used defined IP subnet - VLAN 3
DHCP client Network parameters obtained via DHCP - VLAN 2
Table 3-5: BDU LAN port 3
LAN port 5 Service LAN Port 4 assigned to LAN Port 5 VLAN / IP-subnet.
ADU port 2 BDU LAN Port 4 + ADU LAN Port 2 assigned to VLAN 7
Static IP Used defined IP subnet - VLAN 4
DHCP client Network parameters obtained via DHCP - VLAN 4
Modem controlled LAN Port 1 VLAN's configured by GMU via SNMP
Table 3-6: BDU LAN port 4
Disabled ADU LAN Port 1 disabled.
Service ADU LAN Port 1 assigned to BDU LAN Port 5 VLAN / IP-subnet.
LAN port 3 BDU LAN Port 3 + ADU LAN Port 1 assigned to VLAN 6
Table 3-7: ADU LAN 1
Disabled ADU LAN Port 1 disabled
Service ADU LAN Port 1 assigned to BDU LAN Port 5 VLAN / IP-subnet.
LAN port 4 BDU LAN Port 4 + ADU LAN Port 2 assigned to VLAN 7
Table 3-8: ADU LAN 2
