VLAN table
The VLAN table shows which VLANs are set up per physical Ethernet port on the BDU. U
means Untagged, T means Tagged.
System VLANs
The VLANs 1-8 are defined as System VLANs, used by the BDU/ADU switch. They are not
available for the user.
Important
VLAN 1 through 8 are used internally by the SAILOR XTR GX-R2 antenna
system. Do not use them with external equipment connected to the LAN
ports of the BDU/ACM. A maximum of 12 additional user VLAN is
supported.
VLAN 1 + IP-subnet Default VLAN + Native VLAN (untagged frames on a T port)
OPENAMIP traffic from Modem + SAILOR Management (ADU
CPU - WEB MMI, SSH, IoT)
VLAN 2 + IP-subnet Assigned to BDU LAN 2 in Mode: static and DHCP client
Management of the SAILOR VSAT (ADU CPU)
VLAN 3 + IP-subnet Assigned to BDU LAN 3 in Mode: Static and DHCP client
Management of the SAILOR VSAT (ADU CPU)
VLAN 4 + IP-subnet Assigned to BDU LAN 4 in Mode: Static and DHCP client
Management of the SAILOR VSAT (ADU CPU)
VLAN 5 + IP-subnet Assigned to BDU LAN 5 Management of the SAILOR VSAT
(ADU CPU)
VLAN 6 Assigned to BDU LAN 3 and ADU LAN 1 User traffic, third
party equipment in the ADU
VLAN 7 Assigned to BDU LAN 4 and ADU LAN 2 User traffic, third
party equipment in the ADU
VLAN 8 Assigned to BDU LAN 7 and ADU LAN 7 Internal SAILOR
system traffic, BDU/ADU
Table 3-9: System VLANs
