ColDesi Avance - Satin Stitch Adjustment

53 | P a g e
5.12 Satin Stitch Adjustment
This operation is to adjust the satin width in the design according to the need.
1. Press to enter memory pattern management interface.
2. Select a pattern in the memory pattern image display area.
3. Press to enter memory operation selection interface.
4. Press “Satin Stitch Adjustment” to enter the operation interface.
5. User can press to input new pattern number and name instead of default ones.
6. Press “X Adjust Value” and “Y Adjust Value” to input the value respectively.
7. Press to make the satin stitch adjustment and return to pattern operation selection interface.
Press to quit the adjusting operation and return to pattern operation selection interface.
