5.7 Speed and type of measurement
The Speed function is used to select the type of speed measurement and to adjust the method of
measuring. Three types of measurements are available:
Fixed speed
Incremental Encoder
Measuring Scanner
5.7.1 Fixed speed
At fixed speed the goods are labeled with a constant labeling speed. This speed is also used when
dispensing a label with the Label jog function of the Labeling Mode menu.
SPEED DISPENSING SPEED
Method of measuring
Choice: Fixed Value : 20.0 m/Min
Dispensing Speed
User level: programmer/operator
Operating Mode: RUN/STOP
5.7.2 Inkremental encoder and measuring light barrier
When measuring the speed with an incremental encoder or by a measuring light barrier, the speed of
the goods is measured and they are labelled with this speed:
SPEED INCREMENTAL ENCODER
Method of measuring
Choice: Distance between
Incremental encoder two Pulses : 1.00 mm
SPEED DISTANCE BETWEEN
Method of measuring the Lightbeams
Choice: Measuring
Scanner Value : 14.0 mm
User level: programmer
Operating Mode: STOP
Note:
The distance of 14 mm applies for the standard light barrier of Collamat Stral-
fors AG.
For more informations about the calculation of the speed measuring, refer to
the technical handbook Collamat 8600 and 9100
5999.530-01E 14.01.2004 CSWM 4 23
