COMAC CAL FLOW 38 Installation And Technical Manual

Technical and instalation
manual FLOW 38 Batch Page 44 (of 49) COMAC CAL
s.r.o.
Sandwich (Inter-flanged) design
Diameter
nominal
[mm]
D
1
Outside diameter
of sensor
L
2
Building length
of sensor
H
3
Building height
of sensor
Weight of
detached flow
sensor (kg)
10*,15
51
90
110
2
20
61
90
120
2
25
71
90
130
3
32
82
90
140
3
40
92
110
150
4
50
107
110
165
4
65
127
130
185
5
80
142
130
200
6
100
168
200
226
7
125
194
200
253
9
150
224
200
283
11
200
284
200
340
14
The Table is for PN25.
* Process connection is performed through DN 15 flange
