COMAC INNOVA 55B - Side and Rear Machine Elements

11
MACHINE PREPARATION
The components on the rear part of the footboard are:
11. Emergency button
12. Detergent solution level tube
13. Recovery tank release button
6. SIDE MACHINE ELEMENTS
The elements on the left-hand side of the machine are:
14. Fast water-detergent filling cap
15. Water-detergent filler cap
16. Handle support kit (optional)
7. REAR MACHINE ELEMENTS
The elements on the rear of the machine are:
17. Recovery tank cover
18. Blinking light (optional)
19. Recovery tank drain pipe
20. Squeegee vacuum tube
12
11
13
16
17
18
19
20
14 15
