32. AT THE END OF THE WORK
t the end of the work, and before carrying out any type of maintenance, perform the following operations:
1. Close the tap by moving the knob (1) upwards
2. Lift the brush head by turning the right lever (2) anticlockwise, then lift the squeegee turning the left
lever (3) clockwise. The vacuum motor switches off after a few seconds.
WARNING: If the brush head unit is raised up in ECO mode, the vacuum
motor will return to standard mode to allow the floor to dry properly.
3. Bring the machine to the place provided for draining the water
4. Turn the machine off by turning the key one quarter turn anticlockwise and remove it from the panel.
WARNING: Before performing any maintenance, remove the keys from the
panel and disconnect the battery connector of the machine.
5. Disconnect the tube (4) from its seat, unscrew the drainage cap and empty the recovery tank.
WARNING: This operation must be carried out using gloves to protect against
contact with dangerous solutions.
6. Slide the vacuum tube (5) from the squeegee sleeve
7. Remove the squeegee from the support arm (6) by unscrewing the handwheels (7).
8. Clean well both the squeegee and the rubbers with a jet of water.
fter cleaning the squeegee and rubbers, replace the squeegee on the initial support, firstly inserting
the left pin of the squeegee in the left slot of the arm, then the right pin in the right slot, being careful to
keep the spring and washer on the plate of the arm. This can be simplified by first loosening the
handwheel on the pin. Tighten the handwheel to lock the squeegee in place.
10. Finally insert the squeegee tube in the special sleeve.
11. If you need to empty the solution tank, move the knob (1) downwards
12. Lower the brush head body by means of the relevant lever on the steering column
13. Move the tap (8) outside the brush head body
14. Rotate the tap (8) anticlockwise and wait until the solution tank is empty
15. Close the tap (8) and reposition it on the brush head body
16. Raise the brush head body by means of the relevant lever on the steering column
