24
DAILY MAINTENANCE
PERFORM ALL MAINTENANCE OPERATIONS IN SEQUENCE
33. CLEANING THE RECOVERY TANK
1. Disconnect the tube (1) from its seat, unscrew the drainage cap and empty the recovery tank.
2. Press the button (2) to release and rotate the recovery tank
WARNING: Before performing any maintenance, remove the keys from the
panel and disconnect the battery connector of the machine.
ATTENTION: this operation must be carried out using gloves to protect against
contact with dangerous solutions.
3. Grip the recovery tank and rotate it until the gas spring is resting on the solution tank
4. Remove the vacuum cover (3) and place it in the rear part of the machine (see figure)
5. Clean and rinse the recovery tank.
6. Replace the cap on the drainage hose, then replace the vacuum cover.
7. Rotate the recovery tank to its standard position
WARNING: Be careful not to hit the recovery tank float directly, as this would
enable water to enter the vacuum motor connected to it.
34. CLEANING THE RECOVERY TANK FLOAT
1. Press the button (1) to release and rotate the recovery tank
2. Grip the recovery tank and rotate it until the gas spring is resting on the solution tank
3. Remove the vacuum cover (2) and place it in the rear part of the machine (see figure)
4. Remove the float pre-assembly (3) by rotating it anticlockwise
