11. HANDLING - INSERTING BATTERIES
The batteries must be housed in the special compartment beneath the seat carter. They should be handled
using lifting equipment that is suitable in terms of both weight and coupling system. They must also satisfy
the requirements of Standard CEI 21-5. The dimensions of the battery compartment are: 362mm x 354mm
H290mm.
WARNING: For battery maintenance and daily recharging, you must carefully
follow the instructions provided by the manufacturer or retailer. All installation
and maintenance operations must be carried out by specialised personnel.
WARNING: You are advised to use airtight batteries only, to avoid the leakage
of acids!
WARNING: You are advised to always wear protective gloves, to avoid the risk
of serious injury to your hands.
To insert batteries proceed as follows:
1. Check the main switch is in the “0” position, if this is not the case, turn the key by a quarter of a turn to
the left.
2. Lock the machine by activating the electronic brake, then turn the lever (1) (on the rear right-hand side
of the machine) anticlockwise
3. Make sure the recovery tank is empty, otherwise empty it completely
4. Press the button (2) to release and rotate the recovery tank
5. Grip the recovery tank and rotate it as far as it will go
ATTENTION: You are advised to only lift and move the batteries with lifting
and transportation means suitable for the specific weight and size
6. House the batteries in the compartment, positioning the poles “+” and “-“ opposite each other
