SYMBOLS USED ON THE MACHINE
Main switch or key switch symbol
Used on the instrument panel, to indicate the key switch for machine operation on (I) or off (0)
Symbol denoting acoustic alarm
Used to indicate the acoustic alarm button
Symbol of the reverse movement selector
Used to indicate the button for engaging the reverse gear
Brush coupling/uncoupling symbol
Used to indicate the button that couples or uncouples the brush
ECO mode symbol
Used to indicate the button that activates the ECO mode of the machine
Symbol indicating the maximum temperature of the water used to fill the solution tank
Symbol indicating the position of the solution tank drain pipe
Symbol indicating the position of the recovery tank drain pipe
Indicates the maximum gradient
