42
DAILY MAINTENANCE
DAILY MAINTENANCEDAILY MAINTENANCE
DAILY MAINTENANCE
CLEANING SOLUTION FILTER
CLEANING SOLUTION FILTERCLEANING SOLUTION FILTER
CLEANING SOLUTION FILTER
1.
Unscrew the plug on the solution tank
2.
Take off the filter pulling the cap upwards and clean it thoroughly
3.
Reassemble everything pushing the cap up to the snap on the filter body
CLEANING OF THE SQUEEGEE
CLEANING OF THE SQUEEGEECLEANING OF THE SQUEEGEE
CLEANING OF THE SQUEEGEE
In order to have the best drying results, check that the squeegee is always clean.
To clean the squeegee it is necessary to:
1.
Take off the hose from the squeegee
2.
Loosen the knobs (1) as indicated
3.
Take off the opening and clean it
4.
Clean the inside of the squeegee thoroughly
5.
Clean the squeegee rubbers thoroughly
6.
Reassemble everything once more
DISASSEMBLY OF THE BRUSH
DISASSEMBLY OF THE BRUSHDISASSEMBLY OF THE BRUSH
DISASSEMBLY OF THE BRUSH
This machine is equipped with an automatic brush release system, to avoid troublesome
operating procedures. Go ahead as follows:
1.
Lift the brush base acting upon the lever (1)
2.
Brake the machine acting upon the lever (2)
1
2
3. Turn the key (1) into position “1”, press the brush switch (2); keeping the release
button (4) pressed, push for an instant the lever on the handle bar (3) ad then
release it.
The brush will move for a few instants and will fall at once under the cover.
WARNING!
WARNING!WARNING!
WARNING! During this operation make sure that, there are not any objects
or persons close to the brush.
3
4
1 2
