SYMBOLOGY USED ON THE MACHINE
SYMBOLOGY USED ON THE MACHINESYMBOLOGY USED ON THE MACHINE
SYMBOLOGY USED ON THE MACHINE
Symbol denoting cock
Indicates the cock lever
Indicates the solenoid valve switch
Symbol denoting up-down brush base
Indicates the lever of the brush base lifting
Symbol denoting brush
Indicates the brush motor switch
Symbol denoting suction motor
Indicates the suction motor switch
Symbol denoting up - down of the squeegee
Indicates the squeegee lever
Symbol denoting charge level of the batteries
Symbol denoting brake
It is used on top of the emergency and parking brake lever
It is used to indicate the signal lamp of the hand brake on
Indicates the exhaust pipe of the recovery tank
Indication of the maximum temperature of the solution detergent
Placed near the charging hole of the solution tank
