ComAp InteliDrive FLX LITE - Page 179

ID-FLX Lite Global Guide
179
Setpoint group AIO module Related FW 2.5.0
Range [units] -100 .. 10000 [-]
Default value 0 -
Step 1
Comm object 13656 Related applications
Description
The level for IL-NT-AIO plug-in card Analog input 1, 2, 3, 4 alarm detection.
AnlInAIO3 lev2
6 back to List of setpoints
Setpoint group AIO module Related FW 2.5.0
Range [units] -100 .. 10000 [-]
Default value 0 -
Step 1
Comm object 13657 Related applications
Description
The level for IL-NT-AIO plug-in card Analog input 1, 2, 3, 4 alarm detection.
AnlInAIO4 lev2
6 back to List of setpoints
Setpoint group AIO module Related FW 2.5.0
Range [units] 0 .. 180 [s]
Default value 5 -
Step 1
Comm object 13658 Related applications
Description
Configuration Protection
Under limit Protection is activated only when measured value is under measured level.
Over limit Protection is activated only when measured value is over measured level.
UnderLimit+fls Level 2 protection is activated by sensor fail too.
OverLimit+fls Level 2 protection is activated by sensor fail too.
Note: Plug-in analog inputs protection alarms can be configured following way.
AnlInAIO1 del
6 back to List of setpoints
