InteliLite Global Guide
487
Related FW 1.2.1 Related applications AMF, MRS
Comm object 1375
Description
This output is closed, when Binary Input 2 is active and open when Binary Input 2 is inactive. When Binary
Input 2 is used for BIN protection function then this output is closed when BIN protection alarm is in
Alarmlist.
Image 8.154 Binary Input 2 Status
BIN 2 Status
6 back to Logical binary outputs alphabetically
Related FW 1.2.1 Related applications AMF, MRS
Comm object 1376
Description
This output is closed, when Binary Input 3 is active and open when Binary Input 3 is inactive. When Binary
Input 3 is used for BIN protection function then this output is closed when BIN protection alarm is in
Alarmlist.
Image 8.155 Binary Input 3 Status
BIN 3 Status
6 back to Logical binary outputs alphabetically
