ComAp InteliLite MRS16 User Manual

InteliLite Global Guide
488
Related FW 1.2.1 Related applications AMF, MRS
Comm object 1377
Description
This output is closed, when Binary Input 4 is active and open when Binary Input 4 is inactive. When Binary
Input 4 is used for BIN protection function then this output is closed when BIN protection alarm is in
Alarmlist.
Image 8.156 Binary Input 4 Status
BIN 4 Status
6 back to Logical binary outputs alphabetically
Related FW 1.2.1 Related applications AMF, MRS
Comm object 1378
Description
This output is closed, when Binary Input 5 is active and open when Binary Input 5 is inactive. When Binary
Input 5 is used for BIN protection function then this output is closed when BIN protection alarm is in
Alarmlist.
Image 8.157 Binary Input 5 Status
BIN 5 Status
6 back to Logical binary outputs alphabetically
