InteliLite Global Guide
489
Related FW 1.2.1 Related applications AMF, MRS
Comm object 1379
Description
This output is closed, when Binary Input 6 is active and open when Binary Input 6 is inactive. When Binary
Input 6 is used for BIN protection function then this output is closed when BIN protection alarm is in
Alarmlist.
Image 8.158 Binary Input 6 Status
BIN 6 Status
6 back to Logical binary outputs alphabetically
Related FW 1.2.1 Related applications AMF, MRS
Comm object 1380
Description
This output is closed, when Binary Input 7 is active and open when Binary Input 7 is inactive. When Binary
Input 7 is used for BIN protection function then this output is closed when BIN protection alarm is in
Alarmlist.
Image 8.159 Binary Input 7 Status
BIN 7 Status
6 back to Logical binary outputs alphabetically
