InteliLite Global Guide
503
LBO: I
Related FW 1.2.1 Related applications AMF, MRS
Comm object 39
Description
This output is used for switching between idle speed and nominal speed of the engine during the startup
phase, if this feature (input) is available on the particular engine. In the case of some EFI engines, the
idle/nominal switching is performed over the communication bus.
The output Idle/Nominal closes after the timer Idle Time (page 169) elapses. The Idle Time (page 169) starts
to countdown when Starting RPM (page 166) reached. The underspeed protection is not evaluated during
fixed 5 seconds period after reaching Starting RPM (page 166). A Start Fail protection occurs if the RPM drop
below 2RPM during idle.
Image 8.176 Idle/Nominal
Note: Connect binary output Idle/Nominal to speed governor to switch the speed:
opened = Idle
closed = Nominal
(for normally open contact type)
Idle/Nominal
6 back to Logical binary outputs alphabetically
Related FW 1.2.1 Related applications AMF, MRS
Comm object 37
Description
This output is dedicated to controlling the ignition at a gas engine. The output is closed together with binary
output FUEL SOLENOID (PAGE 493) in the moment when the timer Sd Ventilation Time (page 173) elapsed and
the gen-set reaches at least 30 RPM during cranking. The timer Sd Ventilation Time (page 173) become
active when the gen-set has been stopped for any Sd protection or the controller has been turned on only
before first cranking attempt. The output is opened 500ms after all Additional running engine indication
Additional running engine indications (page 103) will be inactive. The output is opened when the gen-
set has to be stopped or in pause during repeated starts.
Ignition
