InteliPro Reference Guide
4-16
Nominal Freq [Hz]
Nominal mains frequency.
Step: 1 Hz
Range: 45 – 65 Hz
Default setting: 50 Hz
NominMainsPwr [kW]
Nominal power of the protected mains feeder.
Step: 1 kW
Range: 0 – 32000 kW
Default setting: 200 kW
Voltage Setup [ Ph To N / Ph To Ph ]
Method of voltage evaluation. Setting of this setpoint indicates, whether the voltage protections and
control functions are calculated from phase-to-neutral or phase-to-phase voltage.
Ph To N protection is based on phase-to-neutral voltage evaluation
Ph To Ph protection is based on phase-to-phase voltage evaluation
Default setting: Ph To N
Note:
Setting of this setpoint influences evaluation methods of the following protection stages:
- Sync Check (ANSI 25)
- Time Over Current With Voltage Control (ANSI 51V)
- Over Voltage (ANSI 59)
- Under Voltage (ANSI 27)
- Volt (Un)Balance (ANSI 47)
CB1 Prot Timer [s]
Setting of the CB1 Protection timer. For this time after CB1 Feedback de-energization, the output CB1
Protection keeps in de-energized state to prevent premature breaker closing. After this time it goes
back to energized state.
Step: 1 s
Range: 1 - 60 s
0 = OFF, CB1 protection function is disabled
Default setting: 0 s
CB2 Prot Timer [s]
Setting of the CB2 Protection timer. For this time after CB2 Feedback de-energization, the output CB2
Protection keeps in de-energized state to prevent premature breaker closing. After this time it goes
back to energized state.
Step: 1 s
Range: 1 - 60 s
0 = OFF, CB2 protection function is disabled
Default setting: 0 s
Comms Settings
Contr. Addr
Unit identification address number. In case of connection to CAN bus together with other ComAp
controllers, different address than that of the controllers has to be entered.
Range: 1 - 32
Default: 1
COM1 Mode [ DIRECT / MODEM / MODBUS ]
Switch, defining what protocol/mode of communication is used on the plug-in communication module.
DIRECT: InteliPro (LiteEdit) communication protocol
