Note:
For any protection it is possible to set-up the blocking inputs Block 1 or 2. There is no delay of
protection activation after selected Block input is opened.
BackupTrp Del
Time period reserved for circuit breaker opening. If trip event occurs and the appropriate CB Feedback
does not deactivate within this period, the breaker is considered as "failed to open". Bak Com Trp
output is activated and in case that the functionality of CB backup are set-up, the appropriate actions
are taken.
Step: 0,1s
Range: 0 – 10 s
Default setting: 2,0 s
Comm Trp Del
Delay for Del Comm Trp output.
Step: 0.1 s
Range: 0.0 – 20.0 s
Default setting: 0,0 s
Comm Trp Len
Length of pulse on Del Comm Trp output after Comm Trp Del.
Step: 0.1 s
Range: 0.1 – 20.0 s
Default setting: 1,0 s
Auto FR [ DISABLED / ON DEACT / CB1+CB2=0 / NOFAULT+DEL ]
Setting of automatic fault reset functionality.
DISABLED: AutoFaultReset is disabled
ON DEACT: if at least one of the inputs CB1 Feedback or CB2 Feedback is deactivated,
AutoFaultReset is issued immediatelly
CB1+CB2=0: if both CB1 Feedback and CB2 Feedback are deactivated, AutoFaultReset is issued
immediatelly
NOFAULT+DEL: AutoFaultReset is issued in the moment when the measured values are within their
limits (no fault condition) no alarm is active plus the delay adjusted by AutoFR Del
parameter. The timeout starts after the last protection deactivation. The
NOFAULT+DEL option is the only method, which is not dependent on the state of
CB1 Feedback or CB2 Feedback binary inputs.
Default setting: DISABLED
Auto FR Del [ s ]
Delay for activation of AutoFaultReset function in the mode NOFLT+DEL.
Step: 1 s
Range: 0 – 3600 s
Default setting: 10 s
Volt Prot, Freq <> Prot, VectorS Prot, ROCOF Prot, DirOverC Prot, NVD
Prot, MnsRevPwr Prot, Overcurr Prot, EarthFlt Prot, CurrentUnbal
[ ALWAYS / PARALLEL / DISABLED ]
Enabling of the appropriate protection stage
DISABLED: protection disabled
PARALLEL: protection enabled when the CB1 Feedback and CB2 Feedback binary inputs are
active and the assigned blocking input is not active (or there is no blocking input
assigned)
