ComAp InteliPro Comprehensive Guide

InteliPro, SW version 1.0, ©ComAp – May 2011
InteliPro Reference Guide
4-31
DISABLED: situation of dead mains and live bus is not considered as "synchronous" state
Default setting: DISABLED
HotVm DeadVsc [ ENABLED / DISABLED ]
Enabling/disabling the synchro-check function of closing "live" mains to "dead" bus.
ENABLED: situation of live mains (mains voltage within limits) and dead bus (Sync Check voltage
below Dead V Lim) is considered as "synchronous" state
DISABLED: situation of live mains and dead bus is not considered as "synchronous" state
Default setting: DISABLED
DeadVm DeadVsc [ ENABLED / DISABLED ]
Enabling/disabling the synchro-check function of closing "dead" mains to "dead" bus.
ENABLED: situation of dead mains (mains voltage below Dead V Lim) and dead bus (Sync Check
voltage below Dead V Lim) is considered as "synchronous" state
DISABLED: situation of dead mains and dead bus is not considered as "synchronous" state
Default setting: DISABLED
Block By AR [ ENABLED / DISABLED ]
If enabled, the synchro-check will not evaluate synchronous state until the AC Reclosing output is
activated after the trip termination.
ENABLED: The binary output will activate only after the AC Reclosing output is activated
DISABLED: The binary output activates regardless of the state of the AC Reclosing output
Default setting: DISABLED
Dead V Lim [ % ]
Threshold for evaluating the mains or bus voltage as "dead".
Step: 0,1 % of nominal voltage
Range: 0,0 - 50,0 %
Default setting: 20,0 %
Dead T Del [ s ]
If the mains or bus voltage stays under the Dead V Lim threshold for longer than tis time, the voltage
is considered as "dead".
Step: 0,1 s
Range: 0,0 - 150,0 s
Default setting: 5,0 s
SynC Block BI [ Block 1 / Block 2 / Block 1+2 / None ]
Selection of blocking binary input for synchro check protection.
Default setting: None
SynC Trp BO [ Trp 1 / Trp 2 / Trp 1+2 / None ]
Selection of trip binary output for synchro check protection.
Default setting: None
Note:
In case of setting to None, the sync check function has no influence on trip outputs. If any trip output is
selected, then deactivation of that trip output is blocked while the synchronous conditions are not
evaluated. When the synchronous conditions are met, the deactivation of the trip output is no longer
blocked.
