Combilift Ltd C2500-C3000CB O&S Manual
1-7
C2500CB-OM-EN-11
Brake/Inching Pedal
The combined Brake/Inching Pedal has two functions:
Stops drive to slow the machine down.
Permits slow speed, for precise manoeuvring of the
truck in confined spaces - See Section 2 for Operating
Instructions and Conditions.
Accelerator Pedal
The accelerator pedal is located on the floor on the right
hand side of the steering column.
It is used to increase the speed of the engine, therefore
increasing travel speed and / or hydraulic function
speed.
Battery Isolator Switch
This switch is used to disconnect power from the battery
in the event of an emergency.
The switch is located inside the cabin, beside the dash.
When the Combilift is not in use turn switch to ‘OFF’
by pressing switch until it clicks into the closed position.
The Combilift will not power-up unless the switch
is returned to the ‘ON’ position by pulling the switch up.
On
Off
