Combilift Ltd C2500-C3000CB O&S Manual
1-4
C2500CB-OM-EN-11
Engine Management Light (Yellow Light On Dash)
If this light comes on it means the engine control unit
(ECU) has detected a problem with the engine.
If the light is on and the engine is running ok you can
drive the truck. However, it should be checked at the
earliest convenience. If the engine is running poorly
the truck should not be driven.
The ECU will store the fault information that will allow
the fault to be diagnosed when the ECU is connected to
a PC.
Oil Pressure Indicator Light
When the key switch is in the ‘ON’ position, with the
engine at rest, the oil pressure indicator is illuminated.
If the indicator is illuminated when the engine is ‘running’
then this indicates low engine oil pressure and/or
insufficient oil in the sump.
Battery Charge Indicator Light
This charging lamp indicates whether the alternator is
charging the system or not. With the key switch turned
ON and the engine not running, this red charge lamp
should illuminate.
If the charging lamp remains illuminated with the engine
running, it indicates a malfunction of the charging
system or associated components.
Pre-Heat Indicator Light – (diesel engines)
The Pre-heat indicator is a lamp connected to the glow
plugs on the diesel engine.
When operating in cold conditions, wait until the pre-
heat indicator extinguishes before attempting to start
engine
Low fuel level indicator light
The low-level indicator light illuminates whenever the
fuel level on the truck reaches a certain level.
On LPG engines a buzzer will also sound.
Whenever the light illuminates the truck should be
refuelled immediately.
Note
Do NOT run engine if oil pressure indicator is illuminated.
