17/06/2020 14:06
41ISC000
Address
Loop Number
Device Zone
3
2
1
EnabledNewDevice State
More
Remove
OFF
Name
Save
17/06/2020 14:06
ONLed Blink
Software Revision
ID
2.0
3195011485
41ISC000 – Module for conventional zone with isolator
The figure shows the settings screen for module 41ISC000.
This module allows a separately-powered conventional zone to interface with the addressed fire detection system.
For further technical information and module wiring, please refer to the technical manual for this device.
Press “MORE” to access additional settings:
• LED Blink: select ON/OFF to enable/disable LED indications for the device.
If ON, the LED flashes at every panel dialogue cycle; if OFF, the LED does not flash during the dialogue cycle.
To save any new parameters, press “Save” on the main device screen.
45
