Comelit 41CPE118 - Submenus for Selecting the Output Type

• Output pulse type: button used to select the Output type:
◊ Continuous - the signal from the output is continuous
◊ Pulsed - the signal from the output is pulsed (3 sec. on/ 3 sec. o)
◊ One pulse - the signal from the output is a single pulse (5 sec.)
• Type / Function: button used to select the Output type as described previously.
• Edit Outputs Map: screen for entering the inputs on the logic diagram for the output.
• More: screen for filling in the parameters relating to each type of output.
4.6.1 Submenus for selecting the output type
• PERIPHERY: select this option when the output is a periphery device terminal (relay output module).
Press “MORE” to program the following parameters:
17/06/2020 14:06
Periphery device output parameters
2Periphery device address
1Periphery device output relays (1-4)
◊ Periphery device output: enter the relay module output number (from 1 to 4).
To save any new parameters, press “Save”.
