17/06/2020 14:06
Disabled
Send Commands
Disabled
Receive Commands
Enabled
Receive Messages
Present
Panel Status
192
Panel IP Address
168
170
0
Name
Panel Number
2
More
SAVE
4.7.2.2 Panels
After enabling the network, each panel begins to search for other connected panels. If a new panel is found, it is added to the
list of panels in the network. Up to 64 panels can be connected in a network.
To view any panels in the network, scroll through the list of panels using the + & - buttons.
Use the Add command to save the new panel. At this point the status of the panel will change from New to Present. The
panels monitor each other and, if one disappears, its status in the list will change to Fault. The menu can also be used to set
which information is received / sent by the corresponding panel: messages and/or commands.
17/06/2020 14:06
Disabled
Send Commands
Disabled
Receive Commands
Enabled
Receive Messages
Present
Panel Status
192
Panel IP Address
168
170
0
Name
Panel Number
2
More
SAVE
When receiving messages is enabled, the behaviour of the outputs must also be specified, by selecting “MORE”.
Each message can be enabled or disabled. Status changes are only saved after the “Save” button is pressed.
17/06/2020 14:06
Repeat Sounder
Repeat Fire Brigade
Repeat Fault Output
Repeat Fire Protection
Enabled
Enabled
Disabled
Disabled
Messages have the following meanings:
• Repeat Sounder - Repeats the status of the “Sounder” (SND) panel output, including delays.
• Repeat Fire Brigade - Repeats the status of the “Fire Brigade” (Fire R) panel output, including delays.
• Repeat Fire Protection - Repeats the status of the “Fire Protection” (Fire P) panel output, including delays.
• Repeat Fault Output - Repeats the status of the “Fault” panel output.
If one of the fire panels is no longer found within the network, the other panels will show the message “Panel no.X Fault”.
If the IP address of a panel is duplicated, the panels will show the message “Double IP address panel no.X”.
After completing the settings, press “Save” on the main screen.
67
