Technical data GE 300
28 3.3/0518
Technical data
Intercom Server GE 300 / GE 300WR
Expansion housing GEZ 300
Power supply: GE 300: 24 VDC (±5 %)
GE 300WR: 20 – 36 VDC
Emergency power consumption: without cards: 200 mAh
with cards see corresponding data sheet
Power consumption: GE 300: depending on settings in CCT 800
max. 30 W, 60 W or 70 W
GE 300WR: max. 30 W
Frequency range: 50 HZ to 15 kHz (–3 dB)
Total harmonic distortion: < 0.9%
Relay outputs: ax. switching capacity: 60 W / 62.5 VA
max. switching current: 2 A
max. switching voltage: 60 VDC / 30 VAC
Music input: max. 800 mV
rms
at 10 kΩ, 16 kHz
Inputs IN1, IN2: for floating contacts, max. line resistance: 1.5 kΩ
Operating temperature range: 0 °C to +50 °C (+32 °F to +122 °F)
Storage temperature range: –30 °C to +60 °C (–22 °F to +140 °F)
Relative humidity: 20% to 80% not condensing
Mounting: wall mounting
Dimensions (W x H x D): 310 x 210 x 77.5 mm (12.21 x 8.27 x 3.05 in)
Weight incl. package: approx. 1,500 g (3.31 lbs)
Power supply: 24 VAC (±5 %),
24 – 35 VDC
Emergency power consumption: without cards: 200 mAh
with cards: see corresponding data sheet
Power consumption: maximum (All Call): 40 VA
Frequency range: 50 Hz to 15 kHz (–3 dB)
Total harmonic distortion: < 0.9%
Operating temperature range: 0 °C to +50 °C (+32 °F to +122 °F)
Storage temperature range: –30 °C to +60 °C (–22 °F to +140 °F)
Relative humidity: 20% to 80% not condensing
Mounting: wall mounting
Dimensions (W x H x D): 310 x 210 x 77.5 mm (12.21 x 8.27 x 3.05 in)
Weight incl. package: with transformer approx. 2,700 g (5.95 lbs)
without transformer approx.1,550 g (3.42 lbs)
