Commend GE 300 - Additional Housing

1. GE 300 variants GE 300
8 3.3/0518
Overview max. number of digital subscribers
Example: If an Intercom Server GE 300 is operated with an 60 W power supply unit, it is possible to
supply max. 36 subscribers via the Intercom Server using an Intercom Server with an expansion hous-
ing.
Additional housing
Expansion housing GEZ 300
 Expansion housing including power supply with five plug-in slots
 Intercom Server GE 300 required
 Up to 80 subscribers together with Intercom Server GE 300
The following types are available:
Interface housing GEI 300
 Interface housing with two slots for G8 interface cards.
 Intercom Server GE 300 required.
 Power supply via GE 300 or GEZ 300.
Max. number of digital subscribers with power supply via Intercom Server
Power supply
1)
Intercom Server
(GE 300/GE 300WR)
Intercom Server +
expansion housing
(GEZ 300)
Intercom Server +
interface housing
(GEI 300)
Intercom Server +
expansion +
interface housing
(GEZ 300 and GEI 300)
GE 300 30 W 16 16 + 16 12 16 + 12
GE 300 60 W / 70 W 20 20 + 16 20 20 + 12
GE 300WR 30 W 16 16 + 16 12 16 + 12
1)
Power supply refers to Intercom Server. Appropriate configuration in CCT 800 is required (see page 23).
NOTES: Operating more digital subscribers
If more digital subscribers are needed, the following options are available:
 Using external power supply for digital stations (max. 20 digital subscribers per housing can be
operated).
 Using an Intercom Server GE 800.
Type Power supply
GEZ 300EU Transformer 230 V Europe
GEZ 300AU Transformer 230 V Australia
GEZ 300US Transformer 240 V UK
GEZ 300UK Transformer 120 V USA
NOTES: Power supply GEZ 300
The extent of supply of the expansion housing GEZ 300 includes a transformer. Therefore, its power sup-
ply is independent of the Intercom Server. For more information about the power supply see ”
Connection
diagram” on page 15.
