GE 300 LED-status indication
3.3/0518 35
LED status indication “input/output card”
LED status indication “outputs”
LED status indication “inputs”
LED-status Description
LED is blinking in a one
second rhythm
The card is working correctly
LED is permanently off No power, warm start or hardware fault
LED is permanently on Waiting for connection to the main processor (during initialisation)
LED is blinking fast Card inserted in wrong slot
LED-status Description
LED is permanently on Output active
LED is permanently off Output inactive
LED-status Description
LED is permanently on Input active
LED is permanently off Input inactive
