K-series OEM Board User Guide
Power indicator of OEM board
LED indicators of satellites and correction data
⚫ Satellite indicator (R): Flashing N times/5s (N=the number of satellites tracked) Correction data
indicator (L): Flashing 1/s to send or receive correction data.
LED indicators of serial ports
⚫ TX(R): Flashing when outputting data from OEM board
⚫ RX(L): Flashing when OEM board receiving correction data or commands
Power indicator of Interface board.
