K-series OEM Board User Guide
Description
⚫ <signal> supports the key words “mark1” and “mark2”, K726 and K708 only apply the “mark1”, K706
only apply the “mark2”.
⚫ <switch> supports the key words “enable” and “disable”.
⚫ [polarity] supports the key words “positive” and “negative”, which separately represent “positive pulse”
and “negative pulse”.
⚫ [timebias] [timeguard] these two parameters cannot be set by now.
The markcontrol status can be checked by log sysconfig command.
5.14 PPS
Format:
PPSCONTROL <switch> <polarity> <period> <pulse-width>
Description
⚫ <switch> supports “enable” or “disable”, notice that “disable” is invalid.
⚫ <polarity> supports “positive” and “negative”, “positive” means high level pulse mode and
“negative” means low level pulse mode.
⚫ <period> in seconds, the update rate can be up to 10Hz.
⚫ <pulse-width> in microseconds, pulse-width should be less than half of period.
5.15 Freset
This command clears data which is stored in non-volatile memory, and set the baud rate to 115200. No data
log is outputted.
Freset //Reset to the factory default
Log marktimea onnew
Log markposa onnew
Saveconfig
//Time of mark input event
// Position at time of mark input event
//Save configuration
ppscontrol enable positive 1 1000
Saveconfig
//Set PPS as high level pulse with 1ms width per second
//Save configuration
