CompAir Classic 05 - Page 10

Service Kits
Only use genuine CompAir UK Hydrovane parts and approved oils. Oils must not be mixed.
Service kits contents
Item Part Number Quantity Description Chapter Location
KM71 - Maintenance Kit
1
50273
1
Air filter 2A
2
9842
1
‘O’ Ring 2A
3
0053/1
1
P.T.F.E. Seat 2B
4
0071
1
P.T.F.E. Seat 2G, 2N
5
52109
1
‘O’ Ring 2D
6
57596
1
Airzet Seal 2D
7
57738
1
Fibre washer 2A
8
57739
1
Fibre washer 2A
9
57761
1
Gasket 2C
10 57795 1 Gasket 2D
11 58024 1 Gasket 2A
12 9613 1 Bonded seal 2D, 2F
13 9619 1 Bonded seal 2A
14 9704 1 ‘O’ Ring 2B, 2D
15 9711 1 ‘O’ Ring 2G, 2N
16 9715 1 ‘O’ Ring 2C, 2D
17 9717 1 ‘O’ Ring 2C, 2D, 2G, 2N
18 9754 1 ‘O’ Ring 2B
19 9758 1 ‘O’ Ring 2G, 2N
20 9763 1 ‘O’ Ring 2F
21 9804 1 ‘O’ Ring 2B
22 W4-1 1 Square section seal
2D
KS71 - Separator Kit
1
59177 1 Separator Element 2G
2
57803 1 Gasket 2G
3
3515C 1 Thermal Motor 2F
4
9613 1 Bonded Seal 2D, 2F
5
9624 1 Bonded Seal 2F
6
59941 1 Oil Restrictor Plug
7
52866 1 Filter
KT71 - Top Up Kit
1
34222 1 Oil Seal 2J
2
56391 1 Gauge 2M
3
58017-03 2 Shim 2E
4
58017-04 2 Shim 2E
5
58018-03 2 Shim 2E
6
58018-04 2 Shim 2E
7
59370-03 2 Shim 2E
8
59370-04 2 Shim 2E
9
58691 1 Jubilee Clip 2L
