Refer to Health and Safety section before carrying
out any service work.
Page 70
CompAir Hydrovane
3B 01 Single Phase (PUTS) Starter
Item Part Number Description Kit
Quantity
Starter Assembly No.
34368
1 74098 Contactor 1
2 74024 Terminal, double stack 3
3 74025 End section 2
4 74036 Transformer 1
5 56132 Fuse 1A 2
6 59344 OTC board 1
7 56122 Timer 1
8 53494 Timer base 1
9 74067 Knob 1
10 74068 Indicator lens 1
11 72708 Push button 1
12 50432 Hour counter 1
13 72706 Emergency stop push button 1
14 74043 Power outlet socket 1
15 74064 Circuit breaker 1
16 74022 Terminal 1
17 74023 Earth terminal 5
18 74020 Thermal overload 1
1
Starter assembly 34368 = 5.5 kW, 400 Volt, 50 Hz D.O.L. and 380/440 Volt, 60 Hz Standard
