CompAir Hydrovane
3C 02 Single Phase (PUTS) Starter
Item Part Number Description Kit
Quantity
Starter Assembly No.
34390
1 74029 Contactor 1
2 74020 Thermal overload 7.5/5.5kW (460V) 1
3 74021 Thermal overload 5.5kW (208-230V) A/R
4 74030 Thermal overload 7.5kW (208-230V) A/R
5 74022 Terminal 3
6 74023 Earth terminal 1
7 74024 Terminal, double stack 12
8 74025 End section 2
9 74026 Transformer 1
10 56132 Fuse 1A 1
11 74027 Fuse 1.6A 2
12 74038 Emergency stop push button 1
13 74064 Circuit breaker 1
14 74043 Power outlet socket 1
15 74079 Connector, thermal overload A/R
16 74028 End bracket 1
17 74039 Aux. Contact block 1
Starter assembly 34390 = 5.5/7.5 kW, 208-230/460 Volt, 60 Hz D.O.L. Electronic Control
