CompAir Hydrovane
3F 230V 50/60Hz Standard Control Starter
Item Part Number Description Kit
Quantity
Starter Assembly No.
34423
1 74112 Contactor 3
2 74063 Auxilary contact block 1
3 74113 Auxilary contact block 1
4 56378 Timer (Star/Delta) 1
5 74064 Circuit breaker 1
6 56122 Timer 1
7 53494 Timer base 1
8 59344 OTC board 1
9 74024 Terminal, double stack 4
10 74025 End section 2
11 74026 Transformer 1
12 56132 Fuse 1A 2
13 74067 Knob operator (Auto) 1
14 74068 Indicator lamp (Reset) 1
15 72708 Push button (Start) 1
16 50432 Hours counter 1
17 72706 Emergency stop push button 1
18 74074 Auxilary contact block 1
19 74043 Power outlet socket 1
20 74022 Terminal 5
21 74023 Earth terminal 1
22 74021 Thermal overload 1
Starter assembly 34423 = 7.5 kW, 230 Volt, 50/60 Hz Standard Control
