5-54
ArmadaStation Removal and Replacement Procedures
9. Remove the mechanism assembly by pressing down on the two square tabs on the
mechanism assembly cover
1
and pulling the assembly out of the backplane
assembly
2
(Figure 5-52).
Figure 5-52.
Removing the Mechanism Assembly
Reverse the removal procedure described above to install the mechanism assembly.
