ArmadaStation Removal and Replacement Procedures
5-55
5.16 Power Supply
The power supply is located in the left rear corner of the ArmadaStation. It is replaced
as an assembly with its fan. To remove the power supply, follow these steps:
CAUTION:
Do not handle or carry the power supply by the wiring harness. This can
cause damage to the power supply and wiring harness.
1. Prepare the ArmadaStation for disassembly (Section 5.3).
2. Remove the alignment tray assembly (Section 5.4).
3. Remove the rear panel assembly (Section 5.5).
4. Remove the upper case assembly (Section 5.6).
5. Remove the I/O assembly (Section 5.9).
6. Remove the top brace (Section 5.10).
