Compaq ArmadaStation - Page 136

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connector Pin Assignments
A-7
Table A-13
Continued
Pin Signal Pin Signal
143 VBATT 160 CBE3
144 AD[23] 161 CBE2
145 GND 162 IRDY
146 AD[21] 163 DEVSEL
147 AD[19] 164 LOCK
148 AD[17] 165 OERR
149 GND 166 SERR
150 AD[14] 167 GND
151 AD[12] 168 RSVD3
152 AD[10] 169 M 12C CLK
153 AD[08] 170 M 12C DATA
154 GND 171 M RING
155 AD[07] 172 MGND
156 AD[05] 173 M DXTN
157 AD[03] 174 GND
158 AD[01] 175 M DXTP
159 GND 176 MSTRBAT
