Illustrated Parts Catalog
3-3
Table 3-1
Spare Parts: ArmadaStation Components
Item Description Spare Part Number
1 Monitor support cover 272134-001
2 Upper case assembly 272120-001
3 Alignment tray assembly 296536-001
4
4a
4b
4c
Miscellaneous Base Hardware Kit, includes:
Top brace
Drive cage shield
Drive cage (2)
272118-001
5 Power supply 272128-001
6 Mechanism assembly 272130-001
7
7a
7b
Miscellaneous Base Plastics Kit, includes:
Expansion card cage
Half-height blank bezel cover
272121-001
8 I/O assembly
International version
Japanese version
272129-001
272129-002
272129-291
9
9a
9b
9c
9d
9e
Miscellaneous Cable Kit, includes:
Hard drive cable
Diskette drive cable
CD-ROM/audio cable
MultiBay cable
Control panel cable
272123-001
10 Backplane assembly 272132-001
11 Left speaker assembly (includes speaker insulator) 272117-001
12 Rear panel assembly 272122-001
13 Base assembly 272133-001
14 Control panel assembly 272127-001
15 Armada 7000 Half-Height MultiBay Adapter 272124-001
Power cord (not illustrated)
Australian
European
Japanese
U.K. English
U.S. English
121258-008
121258-002
121258-007
121258-003
121258-001
