Compaq ArmadaStation - Page 94

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ArmadaStation Removal and Replacement Procedures
5-41
7. Remove the three screws
1
securing the control panel assembly to the base assembly
(Figure 5-39).
8. Lift the control panel assembly and control panel cable
2
from the base assembly.
Figure 5-39.
Removing the Control Panel Assembly
