Compaq ProLiant 3000 Server Features
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: B-CH01.DOC Last Saved On: 1/5/99 11:24 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Cache Memory and System Architecture
■ 512-KB secondary (L2) cache
■ Highly parallel System Architecture with Dual Memory controllers and
dual peer PCI buses
System Memory
■ Supports registered SDRAM, 60-ns or faster, 32-, 64-, 128-, 256-, or
512-MB DIMMs
■ Expandable to 4 GB
■ Supports up to 8 memory DIMM modules, each DIMM socket supporting
one DIMM module. One module is installed or removed at a time.
Expansion Slots
Eight I/O expansion slots:
■ Five dedicated PCI slots
■ Three shared PCI/ISA slots
Expansion Boards
■ Compaq Netelligent 10/100 TX PCI UTP Controller pre-installed in a
PCI slot
