3-26
Rack-Mountable Server Installation
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: D-CH03.DOC Last Saved On: 1/12/99 1:24 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
WARNING:
To reduce the risk of personal injury, be careful
when pressing the component rail release latches and sliding the
component into the rack. The slide rails could pinch your
fingertips.
3. Press the component rail release latch on either side of the server and
slide the server into the rack.
IMPORTANT:
The first time you slide the component into the rack, you
may have to apply some pressure. After the first time, the ball bearings in the
slide will move easily.
IMPORTANT:
When servicing the server, fully extend the component until
the latches lock. To return the server to the rack, depress the latches and
slide the server into the rack.
4. Secure the server face plate to the front of the rack by screwing the
thumbscrews into the cage nuts.
5. Tighten the thumbscrews before you close the rack door to prevent the
door from hitting protruding thumbscrews.
Attaching the Cable
Management Arm
A double-hinged cable management arm and fasteners ship with each server.
The cable management arm attaches to the server's cable management arm
bracket and to the rear frame of the rack. All cables to and from the server are
tied to this arm. The two hinges allow the cable management arm with attached
cables to swing out of the way when you need to access the server pull-out
trays.
