Compaq ProLiant 3000 Setup And Installation Guide

1-10
Compaq ProLiant 3000 Server Features
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: B-CH01.DOC Last Saved On: 1/5/99 11:24 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
■ Ease of Use - The Integrated Management Display provides a 16x4
character display and four button control panel to easily navigate
through menus.
For information about using the IMD, see Chapter 6.
Supported Drive Configurations
Standard server configurations can include as many as seven Smart Array
family controllers. Each Smart Array controller can support two Compaq
ProLiant Storage Systems or one Compaq ProLiant Storage System and up to
ten 1-inch internal, hot-pluggable Ultra2 hard drives with the Ultra2 simplex
drive cage.
A maximum practical SCSI configuration, optimizing performance and storage,
would include the following:
■ One network interface controller (NIC)
■ Seven Smart Array Controllers
■ Fourteen Compaq ProLiant Storage Systems
■ One hundred and five 18-GB drives
This configuration would yield a total storage capacity of 1890 GB.
