Compaq ProLiant 3000 Setup And Installation Guide

1-3
Compaq ProLiant 3000 Servers Setup and Installation Guide
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: B-CH01.DOC Last Saved On: 1/5/99 11:24 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Media Bays
The Compaq ProLiant 3000 server can house up to 12 mass storage devices.
■ Hot-Plug Drives
❏ Seven 1-inch drives or six 1.6-inch drives (Standard)
❏ Eight 1-inch drives or six 1.6-inch drives with optional Duplex
Drive cage
❏ Ten 1-inch Ultra2 drives with optional Ultra2 simplex drive cage
NOTE
: An Ultra2-compatible array controller must be used with the Ultra2
simplex drive cage option. Connecting the Ultra2 simplex drive cage to the
integrated SCSI ports is not supported.
■ Preinstalled IDE CD-ROM drive
■ Two additional half-height drive bays (removable media area)
■ Preinstalled 3 ½”, 1.44-MB diskette drive
Keyboard
The keyboard connector is hot-pluggable. Any standard keyboard can be
plugged in without powering down the system or causing keyboard errors.
Video
■ Integrated PCI Video Controller provides maximum resolution of
1024 x 768, 256 color, non-interlaced
■ 16 to 16.7 million colors, depending on graphics mode. 1-MB video
SGRAM standard
■ Supports SVGA, VGA, and EGA graphics resolution
