Compaq ProLiant 3000 Setup And Installation Guide

3-25
Compaq ProLiant 3000 Servers Setup and Installation Guide
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: D-CH03.DOC Last Saved On: 1/12/99 1:24 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
1. Pull the slide rails forward from the mounting brackets.
2. Carefully align the server's component rails with the rack's slide rails
and slide the server into the rack.
CAUTION:
Be sure to keep the component parallel to the floor
when sliding the component rails into the slide rails. Tilting the
component up or down could result in damage to the rails.
Figure 3-14. Loading the rack server

Compaq ProLiant 3000 Specifications

General

Brand	Compaq
Model	ProLiant 3000
Category	Server
Language	English
