Rack-Mountable Server Installation
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: D-CH03.DOC Last Saved On: 1/12/99 1:24 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Contents of the rack model server box include:
■ Compaq ProLiant 3000 server
■ Cables - refer to Cabling Guidelines for Compaq ProLiant 3000 Servers
■ Rack mounting hardware (numbers reference Figure 3-1)
1 One pair 26-inch slide rail assemblies
2 One pair slide rail mounting brackets
3 Cable management arm bracket
4 Cable management arm
5 Cable management arm screws
6 Plastic rail covers (one pair)
7 Cable management arm support bracket
❏ Template that can be used to mark the rack for proper attachment of
the rack mounting brackets (not shown)
