Compaq ProLiant 3000 Servers Setup and Installation Guide
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: D-CH03.DOC Last Saved On: 1/12/99 1:24 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
CZR4-012.eps
Top View
Figure 3-11. Cage nut and back of mounting bracket assembly installed
4. After attaching both mounting bracket assemblies to the rack, prepare
the server for mounting in the rack.
