4-9
Compaq ProLiant 3000 Servers Setup and Installation Guide
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: E-CH04.DOC Last Saved On: 1/12/99 1:28 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
3. Install the Processor Power Module associated with the processor.
2
3
1
Figure 4-4. Installing the Processor Power Module
4. Set processor setting switch to the appropriate setting for your processor.
NOTE
: For the appropriate processor setting switch position, please refer to
your server’s Hardware Installation and Configuration poster.
5. Restore server to normal operation. Reverse steps in section "Preparing
the Server."
