Installing Hardware Options
For use with 350-MHz or greater Intel processor-based servers only
Writer: Cheri Stewart Project: Compaq ProLiant 3000 Servers Setup and Installation Guide Comments: 179776-002
File Name: E-CH04.DOC Last Saved On: 1/12/99 1:28 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
0
1
2
3
4
5
8
9
10
11
Figure 4-25. SCSI ID numbers - Single SCSI Channel Ultra2 simplex drive cage
with 1-inch drives
0 4
1 5
2 6
3 Not Used
Figure 4-26. SCSI ID numbers - Single SCSI Channel Wide-Ultra drive cage
(Simplex Mode) with 1-inch drives
